CAT 307 E
Cena bez DPH
Tlač
INFO
Kategória
Pásové rýpadlá
Značka / model
CAT 307 E
Rok výroby
2024
Hodiny prevádzky
500 h
Krajina
Čína
Všeobecná úroveň
1
2
3
4
5
Mascus ID
17EF953B
INFORMÁCIE O CENE
Zvoliť menu
PODROBNOSTI
Skladové č.
1
Typ pohonu
Naftový
Výrobné číslo
1
Počet predchádzajúcich vlastníkov
1
Posledná revízia
2025-06-27
Stav podvozku
Good Condition
Motor
Original
Hrubá hmotnosť
6 900 kg
Výkon motora
41,5 kW (56,4 hp)
Výrobca motora
Original
Registračné číslo
1
Emisná trieda
Stupeň V
Obsah lopaty
0,33 m3
Rozchod kolies
450 mm
Výkon pomocnej hydrauliky
147 l/min
Maximálna rýchlosť
5,50 km/h
Transportné rozmery (DxŠxV)
6070 x 2300 x 2540 mm
Pôvodná farba
Original
Dipper / stick length
1 665 mm
Info o stave/Garancia
1 Year
Vyrobené v štáte
Spojené štáty
Dodacie podmienky
FCA, FOB, CIF, EXW
Certifikácia
EPA, CE
Prídavné zariadenia
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL
Business hours,24 hours, holidays and Sundays
Address: Shanghai City, China
Contact: Jason
Whatsapp: +86 13675656717
Mobile:+86 13675656717
Wechat:13675656717
Email:
Packaging Details
1. Flat frame is more suitable for large construction equipment without disassembly.
2. Containers are the cheapest and fastest.
3. Bulk carriers are more suitable for large construction equipment.
4. Ro-ro shipment is fast and suitable for all kinds of machines.
You can choose any mode of transportation according to your needs.
Príslušenstvo
Drôtená ochrana proti vetvičkám
Klimatizácia
Prídavná hydraulika
Predfilter motora
Skeletonová lyžica
Predhrievanie motora
maják
naftové kúrenie
ovládací joystick
štandardná podkopová lopata
Cable bucket
Ďalšie informácie
Parameter configuration of Caterpillar 307E small Hydraulic Excavator
Specification
Power, traditional power
Joint venture/import by manufacturers
Bucket backhoe
Tonnage (tons)7
The overall working weight of the machine (kg) is 6900
Bucket capacity (m³)0.33
Boom length (mm) : 3700
The length of the bucket pole (mm) is 1665
Performance
Rotational speed (rpm) : 10.8
Rotational torque (Nm)16.3
Walking speed (km/h) : High: 5.1 / Low: 3.2
Climbing ability (%)60
The digging force of the bucket (kN) is 50.6
The digging force of the boom (kN) is 37.1
Maximum traction force (kN)56.9
Power system
Engine model Cat C2.6DI Turbo
Rated power (kw/rpm)41.5
Displacement (L)2.6
Bore × stroke (mm)87×110
Hydraulic system
The main pump type is a load-sensing hydraulic system equipped with a variable displacement piston pump
The maximum flow rate of the main pump (l/min) is 147
Walking hydraulic circuit (Mpa)28
Rotary hydraulic circuit (Mpa)24
The main overflow set pressure (Mpa) is 28
Oil capacity
Fuel tank (L)135.0
Hydraulic oil tank (L)51.0
Hydraulic System (L)94.0
Engine oil change rate (L)10.2
Coolant (L)11.9
Main body size
Total transportation length (mm) : 6070
Total transportation width (mm)2300
The total height of the cab (mm) is 2540
Track grounding length (mm)2120
The total length of the track (mm) is 2760
Track plate width (mm)450
Minimum ground clearance (mm)370
Counterweight ground clearance (mm)775
The rear end rotation radius (mm) is 1750
Scope of work
Maximum excavation radius (mm) : 6300
The maximum excavation radius (mm) of the shutdown surface is 6180
Maximum excavation depth (mm) : 4070
Maximum excavation height (mm) : 7240
Maximum unloading height (mm) : 5190
The width × height (mm) of the push board is 2300×450
The lifting or pushing depth of the bulldozer blade (mm) is 390/350
